High-precision centimeter-level UWB positioning solution Scenario application of UWB positioning technology in the Internet of Things era

      2022-03-10 1005

      High-precision centimeter-level UWB positioning solution Scenario application of UWB positioning technology in the Internet of Things era, UWB (ULTraWideband) is a carrier-free communication technology that uses nanosecond to microsecond non-sinusoidal narrow pulses to transmit data. By transmitting very low power signals over a wider frequency spectrum. UWB technology began to appear as early as the 1960s, mainly for military radar. In 2002, the FCC officially opened UWB, with the 3.1GHz-10.6GHz frequency band as the purpose of indoor communication, and gradually promoted UWB civil wireless communication. With the rise of the Internet of Things, the application of high-precision centimeter-level UWB positioning solution technology has ushered in more opportunities.

      High-precision centimeter-level UWB positioning solution Scenario application of UWB positioning technology in the Internet of Things era

      Compared with other positioning technologies, UWB has many advantages such as high positioning accuracy, good security, high transmission rate, large system capacity, low power consumption, and strong anti-interference ability.


      It is expected that the consumption level (ToC) side will usher in an explosion


      Compared with the consumption level (ToC) application, UWB positioning technology has entered the rapid development period of the enterprise level (ToB) market and has been successfully applied. Our company focuses on providing UWB industry solutions, and has successfully met the management needs of personnel, materials or vehicles in industrial manufacturing, smart power plants, chemical plants, underground spaces, warehousing, judicial and other scenarios. Apple's integration of UWB positioning technology into mobile phones will stimulate the explosion of consumer level (ToC) applications. At present, Apple has obtained the US PulseshapinginteroperabilityPulityPulityPulityBandstems patent for accurate indoor positioning and indoor navigation. The application scenarios of the high-precision centimeter-level UWB positioning solution include non-inductive access control authentication, item positioning, animal positioning, and mobile phone interconnection positioning.


      UWB gradually completes the potential complete industrial chain


      In the ToB market, the UWB technology industry chain consists of chips and solutions. In the ToC market, the UWB technology industry chain is forming components such as chips, modules, and complete machines. In addition, UWB technology has also opened up new markets for FPC, functional structural parts and other industries. Generally speaking, the mobile application of UWB technology is expected to bring a new market of billions of dollars to the module and FPC market. Woxu Communication will also cooperate with partners to jointly promote the development of the complete UWB industry chain.


      Under the data of the Internet of Things era, UWB positioning technology has been applied in more scenarios. With the continuous upgrading of the needs of the Internet of Things industry, the industry's demand for high-precision positioning is increasing. According to authoritative research reports, the application of high-precision positioning technology maintains a high compound annual growth rate every year.


      With the continuous upgrading of the needs of the Internet of Things industry, the industry's demand for high-precision centimeter-level UWB positioning solutions for high-precision positioning is increasing. According to authoritative research reports, the application of high-precision positioning technology maintains a high compound annual growth rate every year. Among them, UWB high-precision positioning technology is widely used in intelligent manufacturing, petrochemical, power energy, tunnels/pipe corridors, warehousing and logistics, public security and judicial industries.


      As an industry-leading UWB high-precision positioning research and application enterprise, the self-developed UWB high-precision positioning system is suitable for different complex environments and achieves different positioning business needs. Through the real-time and accurate positioning of personnel and vehicle materials, extended functions such as electronic fence, intelligent inspection, track playback, regional alarm, video linkage, and attendance management are realized. At present, diversified positioning application solutions have been implemented in many fields:


      1. Electric energy


      In order to comprehensively promote the informatization and standardization of safety management in the power industry, a power personnel positioning management system was launched based on UWB positioning technology. By deploying a positioning base station in the power plant/substation operation area, the operator wears the positioning tag, and the position information of the operator is displayed on the positioning engine with zero delay, effectively supervising and managing the safe operation of the operator in the daily work process, and ensuring the work target of safe production . The system integrates functions such as personnel attendance, two-vote fusion, SOS alarm, video linkage, alarm release, and auxiliary search and rescue.


      2. Petrochemical


      For the high-risk chemical industry, personnel safety management is particularly important. The chemical personnel positioning management system based on the high-precision centimeter-level UWB positioning solution technology fundamentally solves the problems of difficulty in personnel, inspection and security. Explosion-proof base stations are installed in areas such as the refinery area of the chemical plant and the explosion-proof control center. Personnel wear explosion-proof labels to accurately locate personnel in real time, with an average positioning accuracy of 30cm; in case of emergency, operators can use the SOS button on the label for emergency rescue; The customized electronic fence realizes two-way alarm for violations; in addition, the system can also integrate intelligent safety management such as video linkage, intelligent inspection control, division of labor and attendance to ensure personnel safety management and reduce accidents.


      3. Smart Manufacturing 4.0


      With the advent of Industry 4.0, traditional manufacturing is moving towards intelligence and informatization, facing the strong market demand for intelligent manufacturing. Combined with the latest IoT positioning technology, a factory positioning management system based on high-precision centimeter-level UWB positioning solution technology was launched. By deploying indoor positioning base stations in the factory, personnel/materials wear positioning tags to accurately locate the location information of factory personnel/materials in real time, with an average positioning accuracy of 10cm. Through accurate location information, it can realize intelligent management of factory materials, process optimization, efficiency and KPI analysis, make factory control more intelligent, and help Industry 4.0 improve management efficiency.


      4. Tunnel gallery


      In order to meet the safety control of construction personnel and vehicles during tunnel/pipe tunnel construction, combined with the new IoT positioning technology, a tunnel/pipe tunnel location management system based on UWB technology was launched. The base station adopts one-dimensional positioning deployment, and the coverage distance of a single base station can reach 300 meters; personnel and vehicles should wear high-power positioning tags to sense the location information and activity status of personnel and vehicles in the tunnel/pipe gallery, with an average positioning accuracy of 10cm. System integration can fully grasp the trajectory of personnel/vehicles; meet the needs of personnel intelligent attendance; in emergency situations, two-way alarm can be realized; relevant video sensors can display on-site conditions on a large screen, which can more effectively improve operational efficiency and ensure personnel safety at the same time .


      5. Warehousing and logistics


      Warehousing and logistics cargo management solution, combined with high-precision centimeter-level UWB positioning solution positioning technology, the coverage radius of a single base station is not less than 100m; the operator's PDA is bound to the positioning label, and the positioning algorithm is used to achieve accurate positioning of the PDA, and these positioning data are forwarded through the agreement. The management platform realizes the accurate storage of goods, accurate query management, system integration of real-time positioning, trajectory query, data distribution and other functions, effectively improving the level of warehousing and logistics management.


      6. Department of Public Prosecution and Law


      In order to promote the institutionalization and standardization of public security organs, the high-precision centimeter-level UWB positioning solution positioning system is combined with traditional supervision methods to meet the judicial management of visitors and personnel in designated areas, which greatly reduces management security risks. By deploying positioning base stations in judicial / court / case processing centers / prisons and other environments, personnel wear positioning tags to obtain personnel location information and trajectory routes in real time. Customized electronic fence to realize area authority management; through video sensing, on-site pictures can be called to provide location and picture information for event processing.
