Microwave radar induction module robot anti-fall public toilet pit status detection

      2022-05-20 979

      The microwave radar sensing module robot anti-falling intelligent public toilet pit status detection, during the movement process, the robot may encounter downward steps or ground depressions. Without the appropriate sensors to sense and process, the robot is at risk of falling.

      Microwave radar induction module robot anti-fall public toilet pit status detection

      The microwave radar sensing module acts as a ranging sensor and is small in size. High precision. The fast measurement frequency can be used as a robot fall arrest sensor. The radar can detect the front distance information in real time and send it to the robot, so that the robot can react in time, such as braking, decelerating, turning, etc., to avoid falling on steps or depressions.


      Product advantages of microwave radar sensor module:

      1. Small size, easy to embed inside the robot;

      2. The measurement frequency is high, and it can adapt to various operating speeds;

      3. High ranging performance, high energy redundancy, and can adapt to various installation angles;

      4. Low cost, a variety of models can be selected;

      5. UART.IIC.IO interface is optional.


      Application principle:


      The microwave radar sensing module installed on the robot detects the distance information obliquely below in real time from a certain angle. When the road is flat, the distance measurement value will be stable within a certain range; when the road is abnormal, the distance measurement value will exceed a reasonable range, and the distance will suddenly change. It can be judged that there are steps or depressions ahead, and the robot can be controlled to slow down or turn to prevent the robot from falling.


      Tunnel inspection robot for obstacle avoidance


      The speed of vehicles in the tunnel is fast, and the risk factor of manual inspection is high. Automated inspections are now safer and more reliable with more track inspection robots. In order to prevent direct collision between inspection robots, integrated microwave radar sensing modules can be installed on both sides of the inspection robots to monitor obstacles that may appear before and after the inspection robots in real time. When an obstacle appears, the radar range changes, triggering the system to alarm. Then, the system can control the deceleration or emergency stop of the inspection robot, effectively reducing the risk of accidents.


      The advantages of microwave radar sensor module solution:

      1. High measurement frequency, standard 100Hz, high up to 1000Hz, fast response, high adaptability to running speed.

      2. Small FOV, accurate ranging, small size, easy to integrate inside the car body.

      3. High cost performance and high ranging performance.



      Detect the flow and pit status of smart public toilets


      Microwave Radar Induction Module The radar sensor module is used to detect public toilet occupancy and people flow statistics, and synchronize the data to the interactive display screen set up in the public area. From the display screen, toilet staff and managers can intuitively see the use of male and female toilets, the use of the third toilet and the mother-infant room, the total passenger flow of smart public toilets, air quality, water and electricity consumption and other related information. It is convenient for citizens to understand the overall environment of public toilets, and managers can also temporarily monitor the cleanliness of public toilets.


      The advantages of microwave radar sensor module solution:

      1. Technical advantages: small size, light weight, accurate measurement and high refresh frequency;

      2. Implementation advantages: low power consumption (0.35W), support long-term battery power supply;

      3. Competitive advantage: long object recognition distance, suitable for various height toilet installation distances;

      4. Price advantage: consumer price;


      Application advantages:

      1. No additional modification is required;

      2. Accurate detection, no false alarm;

      3. The installation distance is not limited;

      4. Accurately identify black objects;

      5. Not damaged.
